Britwall Acoustic Wall Panel 640x665x17mm Grey Pack of 4

AP002

£69.44 /m²

Pack Price:

OR
? Help Measuring?
Details

Nature perfected the fish scale over millions of years. We made it absorb sound.

The fish scale pattern is one of the oldest motifs in architecture — found in Roman mosaics, Gothic stonework, Art Deco detailing and now the most considered interiors of 2025 and beyond. Overlapping, flowing, endlessly rhythmic. It turns a flat wall into something that moves.

Britwall Modern Fish Scale Acoustic Wall Panels bring that sculptural quality to a 640x665x17mm panel built to do more than look beautiful. The 17mm depth creates genuine shadow play as light shifts across the overlapping scales throughout the day, while PET acoustic felt and MDF underneath absorb echo and reverberation quietly and consistently. The most striking wall in the room — that also happens to be the best-sounding one.

Depth that changes with the light. At 17mm, these are among the deepest panels in the Britwall range — thicker than standard 600x600mm flat-profile designs — which means the fish scale surface catches light from different angles, casting shadow lines that shift from morning to evening. It's not a static finish. It's a living wall.

Organic form. Acoustic function. Each panel pairs a scratch-resistant PVC laminate surface with a sound-absorbing PET + MDF core — a premium sculptural feature wall and genuine acoustic treatment from a single panel, with nothing else required.

Where it belongs: home cinemas and living-room feature walls, studios and creative spaces, offices and meeting rooms, reception areas, restaurants, bars and high-end hospitality interiors — anywhere a premium finish and good acoustics both matter.

Crafted to install with care. Lightweight and modular, the panels bond to any clean, dry, level wall with adhesive or fixings. The fish scale pattern demands precise layout planning — the overlapping scales only read correctly when every panel is correctly oriented and tightly joined. Take the time to dry-lay first. The result is worth it.

Installer-approved, reliably stocked and shipped fast across the UK — trusted by homeowners, landlords, designers and trade alike.

Key Features
  • Modern Fish Scale 3D sculpted design — A flowing, overlapping scale pattern with 17mm of genuine surface depth — one of the deepest profiles in the Britwall range — that catches and shifts light throughout the day for a wall that never looks the same twice.
  • Real sound absorption (PET + MDF core) — Layered PET acoustic felt over MDF absorbs echo and reverberation, bringing acoustic calm to rooms where hard surfaces and open layouts make sound quality suffer.
  • Decoration and acoustics in one premium panel — A sculptural feature wall and genuine acoustic treatment from a single installation — no compromise on the look, no separate treatment to add.
  • Tough, wipe-clean PVC laminate finish — A scratch-resistant surface that maintains the premium fish scale finish in busy homes, hospitality spaces and commercial interiors with minimal upkeep.
  • Precision-format 640x665x17mm pack of 4 — A deeper, larger profile than standard 600x600mm panels, covering a generous feature area per pack with the fish scale flowing seamlessly across every join when laid out correctly.
Installation Guide

Britwall Modern Fish Scale Acoustic Wall Panels – 640x665x17mm | PET + MDF | Pack of 4

You'll need: tape measure, spirit level, pencil, panel adhesive (grab adhesive) or suitable screws/fixings for your wall type, and a fine-tooth saw or sharp blade if trimming.

1. Prep the wall — Surface must be clean, dry, level and free of dust or loose paint. At 17mm depth, these panels have more weight than thinner profiles — ensure your wall surface and fixings are sound before starting.

2. Plan your layout — this is essential with fish scale — The overlapping scale pattern only flows correctly when every panel is oriented identically and edges interlock precisely. Dry-lay all four panels on the floor first, confirm the scale direction (typically flowing downward like natural scales), and mark a level pencil guide line for your starting row. The non-square 640x665mm format means horizontal and vertical orientation are not interchangeable — identify and mark the top edge of each panel before lifting.

3. Choose your fixing — On plaster, plasterboard or smooth solid walls, apply grab adhesive in a generous zig-zag across the back of each panel — the 17mm depth means panels are slightly heavier, so full contact across the back is important. On heavy-duty or uneven surfaces, use mechanical fixings as a primary fix and countersink them into the recessed points between scales.

4. Fix the panels — Start from your bottom guide line and work upward and across. Press each panel firmly for several seconds, butt edges together tightly so the fish scale pattern interlocks cleanly, and check alignment before moving on. Level every row — any drift in the scale direction becomes visible quickly.

5. Finish and settle — Wipe off any squeezed-out adhesive before it dries. Allow full bond/cure time before heavy contact — with the greater depth and weight of this profile, full cure time is more important than with thinner panels.

Care: Wipe clean with a soft, dry or slightly damp cloth. Avoid soaking or abrasive cleaners — the PVC laminate preserves the sculpted finish with minimal maintenance.

Good to know: Indoor use only. The 17mm depth makes these panels slightly heavier than thinner profiles in the range — two people makes installation faster and more accurate, particularly for high walls. Always verify your wall fixings are appropriate for the panel weight before starting.

Shipping and Delivery


Experience the convenience of swift order fulfillment with our top-notch shipping services.

Dimension

600 x 600 x 21 mm
